Επεξεργαστής Intel i5-12600KF 4.9GHz 10 cores 16 threads LGA1700 Tray
CPU Specifications
- Total
Cores 10
- # of Performance-cores 6
- # of Efficient-cores 4
- Total
Threads 16
- Max Turbo
Frequency 4.90 GHz
- Performance-core Max
Turbo Frequency 4.90 GHz
- Efficient-core Max
Turbo Frequency 3.60 GHz
- Performance-core Base
Frequency 3.70 GHz
- Efficient-core Base
Frequency 2.80 GHz
- Cache
20 MB Intel® Smart Cache
- Total L2 Cache 9.5 MB
- Processor Base
Power 125 W
- Maximum Turbo
Power 150
W
Supplemental Information
- Marketing Status Launched
- Launch
Date Q4'21
- Embedded Options
Available No
- Use
Conditions PC/Client/Tablet
- Datasheet View now
Memory Specifications
- Max Memory Size (dependent on
memory type) 128
GB
- Memory
Types Up to
DDR5 4800 MT/s
Up to DDR4 3200 MT/s - Max # of Memory
Channels 2
- Max Memory
Bandwidth 76.8 GB/s
Expansion Options
- Direct Media Interface (DMI) Revision 4.0
- Max # of DMI Lanes 8
- Scalability 1S Only
- PCI Express
Revision 5.0 and 4.0
- PCI Express
Configurations ‡
Up to 1x16+4, 2x8+4
- Max # of PCI
Express Lanes 20
Package Specifications
- Sockets
Supported FCLGA1700
- Max CPU Configuration 1
- Thermal
Solution Specification PCG 2020A
- TJUNCTION 100°C
- Package Size 45.0 mm x 37.5 mm
- Max Operating
Temperature 100 °C
Advanced Technologies
- Intel® Gaussian & Neural Accelerator
3.0
- Intel® Thread
Director Yes
- Intel® Deep
Learning Boost (Intel® DL Boost) on CPU Yes
- Intel® Optane™
Memory Supported ‡ Yes
- Intel® Speed
Shift Technology Yes
- Intel® Turbo
Boost Max Technology 3.0 ‡ No
- Intel® Turbo Boost
Technology ‡
2.0
- Intel® Hyper-Threading
Technology ‡
Yes
- Intel® 64 ‡ Yes
- Instruction
Set 64-bit
- Instruction
Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel®
AVX2
- Idle
States Yes
- Enhanced Intel
SpeedStep® Technology Yes
- Thermal
Monitoring Technologies Yes
- Intel®
Volume Management Device (VMD) Yes
Security & Reliability
- Intel® Standard
Manageability (ISM) ‡ Yes
- Intel® Control-Flow Enforcement Technology
Yes
- Intel® AES New
Instructions Yes
- Secure
Key Yes
- Intel® OS Guard Yes
- Execute Disable Bit
‡ Yes
- Intel® Boot Guard Yes
- Mode-based Execute Control (MBEC) Yes
- Intel® Virtualization Technology
(VT-x) ‡
Yes
- Intel® Virtualization Technology
for Directed I/O (VT-d) ‡ Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
