| Essentials | ||
| Processor Number | i7-6700K | |
| Status | Launched | |
| Launch Date | Q3'15 | |
| Lithography | 14 nm | |
| Performance | ||
| # of Cores | 4 | |
| # of Threads | 8 | |
| Processor Base Frequency | 4.00 GHz | |
| Max Turbo Frequency | 4.20 GHz | |
| Cache | 8 MB SmartCache | |
| Bus Speed | 8 GT/s DMI3 | |
| # of QPI Links | 0 | |
| TDP | 91 W | |
|
-
Supplemental Information |
||
| Embedded Options Available | No | |
| Conflict Free | Yes | |
| Datasheet | ||
| Product Brief | ||
|
-
Memory Specifications |
||
| Max Memory Size (dependent on memory type) | 64 GB | |
| Memory Types | DDR4-1866/2133, DDR3L-1333/1600 @ 1.35V | |
| Max # of Memory Channels | 2 | |
| Max Memory Bandwidth | 34.1 GB/s | |
| ECC Memory Supported | No | |
|
-
Graphics Specifications |
||
| Processor Graphics | Intel HD Graphics 530 | |
| Graphics Base Frequency | 350.00 MHz | |
| Graphics Max Dynamic Frequency | 1.15 GHz | |
| Graphics Video Max Memory | 64 GB | |
| Graphics Output | eDP/DP/HDMI/DVI | |
| 4K Support | Yes, at 60Hz | |
| Max Resolution (Intel WiDi) | 1080p | |
| Max Resolution (HDMI 1.4) | 4096x2304@24Hz | |
| Max Resolution (DP) | 4096x2304@60Hz | |
| Max Resolution (eDP - Integrated Flat Panel) | 4096x2304@60Hz | |
| Max Resolution (VGA) | N/A | |
| DirectX* Support | 12 | |
| OpenGL* Support | 4.4 | |
| Intel Quick Sync Video | Yes | |
| Intel InTru 3D Technology | Yes | |
| Intel Wireless Display | Yes | |
| Intel Clear Video HD Technology | Yes | |
| Intel Clear Video Technology | Yes | |
| # of Displays Supported | 3 | |
| Device ID | 0x1912 | |
|
-
Expansion Options |
||
| Scalability | 1S Only | |
| PCI Express Revision | 3.0 | |
| PCI Express Configurations | Up to 1x16, 2x8, 1x8+2x4 | |
| Max # of PCI Express Lanes | 16 | |
|
-
Package Specifications |
||
| Sockets Supported | FCLGA1151 | |
| Max CPU Configuration | 1 | |
| Thermal Solution Specification | PCG 2015D (130W) | |
| TCASE | 64°C | |
| Package Size | 37.5mm x 37.5mm | |
| Low Halogen Options Available | See MDDS | |
|
-
Advanced Technologies |
||
| Intel Turbo Boost Technology | 2.0 | |
| Intel vPro Technology | No | |
| Intel Hyper-Threading Technology | Yes | |
| Intel Virtualization Technology (VT-x) | Yes | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes | |
| Intel VT-x with Extended Page Tables (EPT) | Yes | |
| Intel TSX-NI | Yes | |
| Intel 64 | Yes | |
| Instruction Set | 64-bit | |
| Instruction Set Extensions | SSE4.1/4.2, AVX 2.0 | |
| Idle States | Yes | |
| Enhanced Intel SpeedStep Technology | Yes | |
| Thermal Monitoring Technologies | Yes | |
| Intel Identity Protection Technology | Yes | |
| Intel Stable Image Platform Program (SIPP) | No | |
| Intel Small Business Advantage | Yes | |
|
-
Intel Data Protection Technology |
||
| Intel AES New Instructions | Yes | |
| Secure Key | Yes | |
| Intel Software Guard Extensions (Intel SGX) | Yes | |
| Intel Memory Protection Extensions (Intel MPX) | Yes | |
|
-
Intel Platform Protection Technology |
||
| OS Guard | Yes | |
| Trusted Execution Technology | No | |
| Execute Disable Bit | Yes | |
| Intel Device Protection Technology with Boot Guard | Yes | |
